CFM-4015B-1135-415-22
24 V, 30 mA, 40 x 40 x 15 mm, Tachometer Signal, PWM Control Signal, Dc Fan
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 15.61 |
|
| Rated Speed (RPM) | 13500 |
|
| Air Flow (m³/min) | 0.442 |
|
| Static Pressure (inH2O) | 0.92 |
|
| Noise (dBA) | 41.5 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 50 |
|
| Rotation Detector | No |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | Yes |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 40 x 40 x 15 |
|
| IP Rating | No IP Rating |
|
| Series | CFM-40B |
|
