CFM-3007CF-060-188-20
5 V, 0.09 A, 30 x 30 x 7 mm, Tachometer Signal, omniCOOL™ Dc Axial Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 1.98 |
|
| Rated Speed (RPM) | 6000 |
|
| Static Pressure (inH2O) | 0.06 |
|
| Noise (dBA) | 18.8 |
|
| Voltage Rating (Vdc) | 5 |
|
| Max Input Current (mA) | 90 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 30 x 30 x 7 |
|
| Series | CFM-30CF |
|
