Specifications
Type | Description | |
---|---|---|
Connector Type | Jack |
|
Inner Diameter (mm) | 2 |
|
Outer Diameter (mm) | 6.3 |
|
Insertion Depth/Length (mm) | 9.7 |
|
Mounting Style | Through Hole |
|
Orientation | Vertical |
|
Voltage Rating (Vdc) | 24 |
|
Current Rating (A) | 5 |
|
Number of Conductors | 2 |
|
Internal Switch(es) | 1 |
|
Shielding | No |
|
Dimensions LxWxH (mm) | 13.2 x 8.7 x 10.7 |
|
