CFM-A238V-326-440-20
Recommended Replacement
CFM-A238-43-20
48 V, 0.36 A, 120 x 120 x 38 mm, Dc Fan, Tachometer Signal
48 V, 138 mA, 120 x 120 x 38 mm, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 116 |
|
| Rated Speed (RPM) | 2600 |
|
| Static Pressure (inH2O) | 0.26 |
|
| Noise (dBA) | 44 |
|
| Voltage Rating (Vdc) | 48 |
|
| Max Input Current (mA) | 138 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
