CFM-8020V-142-450-11
Recommended Replacement
CFM-8020V-133-380-11
12 V, 150 mA, 80 x 80 x 20 mm, Dc Fan, Rotation Detector Signal
12 V, 265 mA, 80 x 80 x 20 mm, Dc Fan, Rotation Detector Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 49 |
|
| Rated Speed (RPM) | 4200 |
|
| Static Pressure (inH2O) | 0.31 |
|
| Noise (dBA) | 45 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 265 |
|
| Tachometer Signal | No |
|
| Rotation Detector | Yes |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 80 x 80 x 20 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
