SIM Card Connectors

Same Sky’s line of SIM card connectors offers a variety of SIM, micro-SIM, and nano-SIM connector types. Our SIM card connector models feature push in/pull out, push in/auto eject out, and hinged insertion styles and ultra-compact profiles as low as 1.13 mm. Housed in surface mount packages with gold plated contacts and contact options from 6 to 16, these SIM card connectors provide reliable connections for a range of consumer and mobile applications.

Reset All

Filters | Reset All

Stacked Scrolling

Results 40

Reset All

Connector Type

Connector

Connector and Ejector

Reset

Compatible Card

Micro SIM Card

Nano SIM Card

SIM Card

Reset

Removal Method

Hinged

Push In, Auto Eject Out

Push In, Pull Out

Reset

Number of Contacts

Min

Max

Reset

Height Above Board (mm)

Min

Max

1.13

1.24

1.25

1.35

1.37

1.38

1.4

1.42

1.43

1.44

1.45

1.5

1.54

1.55

1.56

1.7

1.8

1.85

1.88

2.23

2.3

2.8

Reset

Card Detect Switch

Yes

Reset

Contact Finish Thickness

3 µin

Gold Flash

Reset

Product Release New Products

Purchase Buy Online at sameskydevices.com Normally Stocked in Distribution

Resources 3D Model Available PCB Footprint Available

Results 40

of ?

Model Number	Connector Type	Compatible Card	Mounting Style	Removal Method	Number of Contacts	Height Above Board (mm)	Card Detect Switch	Contact Finish	Contact Finish Thickness	Series	Data Sheet
NSIM-13-A Nano SIM Card Connectors, 8 Contacts, Card Detect Switch, Push In, Auto Eject Out, Surface Mount, 1.24 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Nano SIM Card	Surface Mount	Push In, Auto Eject Out	8	1.24	Yes	Gold Plated	Gold Flash	--	NSIM-13-A.pdf
NSIM-12-A Nano SIM Card Connectors, 8 Contacts, Card Detect Switch, Push In, Auto Eject Out, Surface Mount, 1.24 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Nano SIM Card	Surface Mount	Push In, Auto Eject Out	8	1.24	Yes	Gold Plated	Gold Flash	--	NSIM-12-A.pdf
SIM-14-B SIM Card Connectors, 16 (8+8) Contacts, Dual Card Slot, Push In, Pull Out, Surface Mount, 3.0 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	SIM Card	Surface Mount	Push In, Pull Out	16	3	No	Gold Plated	Gold Flash	--	SIM-14-B.pdf
NSIM-15-C Nano SIM Card Connectors, 6 Contacts, Hinged, 1.45 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Hinged	6	1.45	No	Gold Plated	Gold Flash	--	NSIM-15-C.pdf
MSIM-11-C Micro SIM Card Connectors, 6 Contacts, Hinged, Surface Mount, 1.50 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Micro SIM Card	Surface Mount	Hinged	6	1.5	No	Gold Plated	Gold Flash	--	MSIM-11-C.pdf
NSIM-16-B Nano SIM Card Connectors, 6 Contacts, Push In, Pull Out, Surface Mount, 1.55 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	6	1.55	No	Gold Plated	Gold Flash	--	NSIM-16-B.pdf
NSIM-14-C Nano SIM Card Connectors, 6 Contacts, Hinged, 1.45 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Hinged	6	1.45	No	Gold Plated	Gold Flash	--	NSIM-14-C.pdf
NSIM-5-B Nano SIM Card Connectors, 7 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.4 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	7	1.4	Yes	Gold Plated	Gold Flash	--	NSIM-5-B.pdf
NSIM-8-B Nano SIM Card Connectors, 7 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.38 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	7	1.38	Yes	Gold Plated	Gold Flash	--	NSIM-8-B.pdf
MSIM-12-A SIM Card Connector, 9 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.54 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	9	1.54	No	Gold Plated	Gold Flash	--	MSIM-12-A.pdf
MSIM-2-A Micro SIM Card Connector, 6 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.37 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	--	1.37	No	Gold Plated	Gold Flash	--	MSIM-2-A.pdf
NSIM-7-A Nano SIM Card Connectors, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.37 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Nano SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.37	Yes	Gold Plated	Gold Flash	--	NSIM-7-A.pdf
MSIM-7-A Micro SIM Card Connector, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.43 mm Haight Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.43	Yes	Gold Plated	Gold Flash	--	MSIM-7-A.pdf
MSIM-1-A Micro SIM Card Connector, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.37 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.37	Yes	Gold Plated	Gold Flash	--	MSIM-1-A.pdf
MSIM-9-B Micro SIM Card Connector, 8 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.5 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Micro SIM Card	Surface Mount	Push In, Pull Out	8	1.5	No	Gold Plated	Gold Flash	--	MSIM-9-B.pdf
NSIM-2-C Nano SIM Card Connectors, 6 Contacts, Connector, Hinged, Surface Mount, 1.4 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Hinged	6	1.4	Yes	Gold Plated	Gold Flash	--	NSIM-2-C.pdf
NSIM-4-B Nano SIM Card Connectors, 6 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.44 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	6	1.44	Yes	Gold Plated	Gold Flash	--	NSIM-4-B.pdf
MSIM-5-B Micro SIM Card Connector, 6 Contacts, Connector, Push In, Pull Out, Surface Mount, 2 mm Height Above Board, 3u" Gold Datasheet Stock Check	Connector	Micro SIM Card	Surface Mount	Push In, Pull Out	6	2	No	Gold Plated	3 µin	--	MSIM-5-B.pdf
MSIM-8-A Micro SIM Card Connector, 6 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.8 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Hinged	6	1.8	No	Gold Plated	Gold Flash	--	MSIM-8-A.pdf
NSIM-1-A Nano SIM Card Connectors, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.37 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Nano SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.37	Yes	Gold Plated	Gold Flash	--	NSIM-1-A.pdf
MSIM-6-A Micro SIM Card Connector, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.88 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.88	Yes	Gold Plated	Gold Flash	--	MSIM-6-A.pdf
NSIM-10-B Nano SIM Card Connectors, 7 Contacts, Connector, Push In, Pull Out , Surface Mount, 1.42 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	7	1.42	No	Gold Plated	Gold Flash	--	NSIM-10-B.pdf
MSIM-11-A SIM Card Connector, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.54 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.54	Yes	Gold Plated	Gold Flash	--	MSIM-11-A.pdf
NSIM-3-C Nano SIM Card Connectors, 7 Contacts, Connector, Hinged, Surface Mount, 1.35 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Hinged	7	1.35	Yes	Gold Plated	Gold Flash	--	NSIM-3-C.pdf
MSIM-4-A Micro SIM Card Connector, 9 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.56 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Micro SIM Card	Surface Mount	Push In, Auto Eject Out	9	1.56	Yes	Gold Plated	Gold Flash	--	MSIM-4-A.pdf
NSIM-6-A Nano SIM Card Connectors, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.25 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	Nano SIM Card	Surface Mount	Push In, Auto Eject Out	7	1.25	Yes	Gold Plated	Gold Flash	--	NSIM-6-A.pdf
MSIM-3-C Micro SIM Card Connector, 8 Contacts, Connector, Hinged, Surface Mount, 1.5 mm Hight Above Board, Gold Flash Datasheet Stock Check	Connector	Micro SIM Card	Surface Mount	Hinged	8	1.5	No	Gold Plated	Gold Flash	--	MSIM-3-C.pdf
MSIM-10-B SIM Card Connector, 6 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.8 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	SIM Card	Surface Mount	Push In, Pull Out	6	1.8	No	Gold Plated	Gold Flash	--	MSIM-10-B.pdf
NSIM-11-B Nano SIM Card Connectors, 6 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.13 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	Nano SIM Card	Surface Mount	Push In, Pull Out	6	1.13	No	Gold Plated	Gold Flash	--	NSIM-11-B.pdf
SIM-4-A SIM Card Connector, 7 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 2 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	7	2	Yes	Gold Plated	Gold Flash	--	SIM-4-A.pdf
SIM-8-B SIM Card Connector, 6 Contacts, Connector, Push In, Pull Out, Surface Mount, 1.7 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	SIM Card	Surface Mount	Push In, Pull Out	6	1.7	No	Gold Plated	Gold Flash	--	SIM-8-B.pdf
SIM-10-A SIM Card Connector, 10 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.85 mm haight Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	10	1.85	Yes	Gold Plated	Gold Flash	--	SIM-10-A.pdf
SIM-2-A SIM Card Connector, 8 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.85 mm Hight Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	8	1.85	Yes	Gold Plated	Gold Flash	--	SIM-2-A.pdf
SIM-11-A SIM Card Connector, 8 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 1.85 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	8	1.85	Yes	Gold Plated	Gold Flash	--	SIM-11-A.pdf
SIM-3-A SIM Card Connector, 8 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 2.3 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	8	2.3	Yes	Gold Plated	Gold Flash	--	SIM-3-A.pdf
SIM-13-A SIM Card Connector, 8 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 2.23 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	8	2.23	Yes	Gold Plated	Gold Flash	--	SIM-13-A.pdf
SIM-5-A SIM Card Connector, 9 Contacts, Connector and Ejector, Push In, Auto Eject Out, Surface Mount, 2 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	9	2	Yes	Gold Plated	Gold Flash	--	SIM-5-A.pdf
SIM-9-C SIM Card Connector, 6 Contacts, Connector, Hinged, Surface Mount, 2.8 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	SIM Card	Surface Mount	Hinged	6	2.8	No	Gold Plated	Gold Flash	--	SIM-9-C.pdf
SIM-12-B SIM Card Connector, 8 Contacts, Connector, Push In, Pull Out, Surface Mount, 3 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector	SIM Card	Surface Mount	Push In, Pull Out	8	3	Yes	Gold Plated	Gold Flash	--	SIM-12-B.pdf
SIM-1-A SIM Card Connector, 8 Contacts, Connector and Ejector, Push In-Auto Eject Out, Surface Mount, 1.85 mm Height Above Board, Gold Flash Datasheet Stock Check	Connector and Ejector	SIM Card	Surface Mount	Push In, Auto Eject Out	8	1.85	Yes	Gold Plated	Gold Flash	--	SIM-1-A.pdf
