TS31-46-35-BK-B-260-RA-SMT-TR
4.6 x 3.85 mm; 3.5 mm Actuator Height Off PCB; w/ Boss; 260 gf; Black; Right Angle; Surface Mount; SPST; Tactile Switch
Specifications
| Type | Description | |
|---|---|---|
| Switch Type | Tactile |
|
| Circuit | SPST |
|
| Actuator Height (mm) | 1.2 |
|
| Actuator Travel (mm) | 0.2 |
|
| Operating Force (gf) | 160 ± 50 |
|
| Voltage Rating (Vdc) | 12 |
|
| Current Rating (mA) | 50 |
|
| Contact Resistance (mΩ) | 100 |
|
| Insulation Resistance (MΩ at 100 Vdc) | 100 |
|
| Withstanding Voltage (Vac for 1 min) | 250 |
|
| Mounting Style | Surface Mount |
|
| Termination | Gull Wing |
|
| Lifecycles | 100000 |
|
| Illumination | No |
|
| Illumination Color | None |
|
| Operating Temp. (°C) | -40 ~ 85 |
|
| Dimensions LxWxH (mm) | 4.6 x 1.8 x 2.3 |
|
| Dimensions LxWxH (in) | 0.181 x 0.07 x 0.09 |
|
| Series | TS31 |
|
