DS04-254-2S-06BK
6 Position, Through Hole, 2.54 mm Pitch, Flat Slide Actuator, Flat Bottom, Short Pin, DIP Switch
Specifications
| Type | Description | |
|---|---|---|
| Actuator Level | Flat |
|
| Actuator Type | Slide |
|
| Bottom | Flat |
|
| Pin | Short |
|
| Switch Type | DIP |
|
| Mounting Style | Through Hole |
|
| Pitch (mm) | 2.54 |
|
| Switching Voltage Rating (Vdc) | 24 |
|
| Non-Switching Voltage Rating (Vdc) | 50 |
|
| Number of Positions | 6 |
|
| Non-Switching Current Rating (mA) | 100 |
|
| Switching Current Rating (mA) | 25 |
|
| Termination | PC Pin |
|
| Orientation | Horizontal |
|
| Cap | No |
|
| Dimensions LxWxH (mm) | 16.24 x 6.2 x 3.66 |
|
| Dimensions LxWxH (in) | 0.64 x 0.24 x 0.14 |
|
| Washable | No |
|
| Series | DS04-254 |
|
