Specifications
| Type | Description | |
|---|---|---|
| Relay Type | Signal |
|
| Coil Voltage (V) | 24 |
|
| Nominal Coil Power (mW) | 330 |
|
| Contact Form | SPDT (1 Form C) |
|
| Contact Rating VAC @ 1 A | 120 |
|
| Contact Rating VDC @ 1 A | 30 |
|
| Max Switching Voltage (VDC) | 24 |
|
| Max Switching Voltage (VAC) | 120 |
|
| Max Switching Current (A) | 2 |
|
| Contact Resistance (mΩ) | 50 |
|
| Mounting Style | Through Hole |
|
| Termination | Pc Pins |
|
| Contact Material | AuAg Overlay |
|
| Dimensions LxWxH (in) | 0.4 x 0.29 x 0.39 |
|
| Dimensions LxWxH (mm) | 10.2 x 7.4 x 10 |
|
| Series | SR2 |
|
