Specifications
| Type | Description | |
|---|---|---|
| Relay Type | Signal |
|
| Coil Voltage (V) | 5 |
|
| Nominal Coil Power (mW) | 150 |
|
| Contact Form | SPDT (1 Form C) |
|
| Contact Rating VAC @ 1 A | 125 |
|
| Contact Rating VDC @ 1 A | 24 |
|
| Max Switching Voltage (VDC) | 60 |
|
| Max Switching Voltage (VAC) | 125 |
|
| Max Switching Current (A) | 2 |
|
| Contact Resistance (mΩ) | 50 |
|
| Mounting Style | Through Hole |
|
| Termination | Pc Pins |
|
| Contact Material | AuAg Overlay |
|
| Dimensions LxWxH (in) | 0.48 x 0.29 x 0.4 |
|
| Dimensions LxWxH (mm) | 12.3 x 7.3 x 10.2 |
|
| Series | SR3 |
|
