Specifications
| Type | Description | |
|---|---|---|
| Connector Type | Receptacle |
|
| Inner Diameter (mm) | 2.5 |
|
| Outer Diameter (mm) | 5.5 |
|
| Mounting Style | Cable - Overmold |
|
| Orientation | Vertical |
|
| Voltage Rating (Vdc) | 20 |
|
| Current Rating (A) | 8 |
|
| Number of Conductors | 2 |
|
| Internal Switch(es) | 0 |
|
| Shielding | No |
|
| Insertion Depth/Length (mm) | 11.5 |
|
