Specifications
Type | Description | |
---|---|---|
Connector Type | Jack |
|
Inner Diameter (mm) | 1.65 |
|
Outer Diameter (mm) | 5.15 |
|
Insertion Depth/Length (mm) | 8 |
|
Mounting Style | Through Hole |
|
Orientation | Horizontal |
|
Voltage Rating (Vdc) | 24 |
|
Current Rating (A) | 2.5 |
|
Number of Conductors | 2 |
|
Internal Switch(es) | 1 |
|
Shielding | No |
|
Dimensions LxWxH (mm) | 12.5 x 9 x 6 |
|
