DS02-254 Series

DS02-254-2L-10BE

This product has been discontinued. If you have any questions or concerns, please review the EOL notice.

10 Position, Through Hole, 2.54 mm Pitch, Flat Piano Slide Actuator, Flat Bottom, Long Pin, DIP Switch

Specifications

Type Description
Select
Actuator Level Flat
Actuator Type Piano
Bottom Flat
Pin Long
Switch Type DIP
Pitch (mm) 2.54
Switching Voltage Rating (Vdc) 24
Non-Switching Voltage Rating (Vdc) 50
Non-Switching Current Rating (mA) 100
Number of Positions 10
Switching Current Rating (mA) 25
Mounting Style Through Hole
Termination PC Pin
Orientation Vertical
Cap No
Washable No
Dimensions LxWxH (mm) 26.97 x 10.8 x 9.6
Dimensions LxWxH (in) 1.06 x 0.43 x 0.38
Series DS02-254

Technical Docs

Datasheet
