Specifications
| Type | Description | |
|---|---|---|
| Fan Type | Axial Fan |
|
| Bearing Type | Ball |
|
| Air Flow at 50Hz (CFM) | 149.33 |
|
| Air Flow at 60Hz (CFM) | 87.36 |
|
| Rated Speed at 50Hz (RPM) | 2400 |
|
| Rated Speed at 60Hz (RPM) | 1400 |
|
| Static Pressure at 50Hz (inH2O) | 0.26 |
|
| Static Pressure at 60Hz (inH2O) | 0.1 |
|
| Noise at 50Hz (dBA) | 49.1 |
|
| Noise at 60Hz (dBA) | 35.8 |
|
| Voltage Rating (Vac) | 110 |
|
| Operating Voltage (Vdc) | 110 ~ 125 |
|
| Current Rating at 50Hz (mA) | 290 |
|
| Current Rating at 60Hz (mA) | 280 |
|
| Rated Power at 60Hz (W) | 19.8 |
|
| Rated Power at 50Hz (W) | 21.3 |
|
| Max Input Current (mA) | 320 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (in) | 6.77 x 5.91 x 2.01 |
|
| Dimensions LxWxH (mm) | 172 x 150 x 51 |
|
| Series | CAF-A7B |
|
