C14N32P-B2

C14N32P-B2

14 mm, 5 Vdc, 32 PPR, 130 mm Cable w/Connector Termination, Optical Panel Mount Encoder

Datasheet

Specifications

Type Description
Select
Resolution (PPR) 32
Input Voltage (Vdc) 4.75 ~ 5.25
Shaft Length (mm) 17.5
Shaft (Bore) Ø (mm) 6
Detent No
Orientation Vertical
Termination Cable
Push Switch Yes
Series C14
