C14N32N-C2

C14N32N-C2

14 mm, 5 Vdc, 32 PPR, Header I, Optical Panel Mount Encoder

Datasheet

Specifications

Type Description
Select
Resolution (PPR) 32
Input Voltage (Vdc) 4.75 ~ 5.25
Shaft (Bore) Ø (mm) 6
Shaft Length (mm) 17.5
Detent No
Orientation Vertical
Termination Header
Push Switch No
Series C14

Technical Docs

Datasheet

Other Resources
