C14D32P-B1 Optical Panel Mount Encoder
C14D32P-B1 Optical Panel Mount Encoder
C14D32P-B1 Optical Panel Mount Encoder Alternate View

C14D32P-B1

14 mm, 5 Vdc, 32 PPR, 130 mm Cable w/Connector Termination, Optical Panel Mount Encoder

Datasheet

Specifications

Type Description
Select
Base Size (mm) 14 x 16
Resolution (PPR) 32
Input Voltage (Vdc) 4.75 ~ 5.25
Shaft Length (mm) 22.22
Shaft (Bore) Ø (mm) 3.175
Detent Yes
Orientation Vertical
Termination Cable
Push Switch Yes
IP Rating No IP Rating
Series C14

Technical Docs

Datasheet
