PTN09S1-H20115K1B

PTN09S1-H20115K1B
PTN09S1-H20115K1B Alternate View

PTN09S1-H20115K1B

9.5 mm, Horizontal, Single Section, Linear, 20K, Through Hole, Knurled Shaft Rotary Potentiometer

Datasheet

Specifications

Type Description
Select
Potentiometer Type Rotary
Size (mm) 9.5
Termination Straight Pc Pins
Taper Linear
Orientation Horizontal
Resistance (kΩ) 10
Shaft Length (mm) 20
Resistance Tolerance (%) 20
Number of Turns 1
Bushing 7 mm
Detent No Detent
Mounting Type Through Hole
Number of Gangs 1
Power (W) 0.05
Rotation (°) 300
Shaft Style D-cut
Series PTN09SX
