Specifications
| Type | Description | |
|---|---|---|
| Terminal Type | PC Pin |
|
| Termination | Press-Fit |
|
| Terminal Style | Single End |
|
| Length Above Flange (mm) | 2.6 |
|
| Length Below Flange (mm) | 3.96 |
|
| Pin Size Above Flange (mm) | 1.45 |
|
| Pin Size Below Flange (mm) | 1.35 |
|
| Contact Finish Thickness (µin) | 10 |
|
| Contact Material | Copper Alloy |
|
| Contact Finish | Gold Plated |
|
| Flange Diameter (mm) | 1.35 |
|
| Length Overall (mm) | 6.56 |
|
| Mounting Hole Diameter (mm) | 0.46 |
|
