CDM1206-12A-MP-R9-67

12 Pins, Panel Mount, Pc Pins, Rear Fastened PG9, A-Coding, Screw Copper Alloy, IP67, M12 Male Circular Connector Jack

Datasheet

Specifications

Type Description
Select
Connector Type Jack
Connector Size M12
Mounting Style Panel Mount
Connector Style Male
Shielding No
Termination Pc Pins
Voltage Rating (Vac) 30
Current Rating (A) 1.5
IP Rating IP67
Number of Positions 12
Pin Size (mm) 0.6
Coding A
Mounting Thread Size PG9
Color Silver
Contact Finish Gold Plated
Fastening Type Threaded Rear
Shell Finish Brass with Nickel Plating
Shell Size (mm) 12
Series CDM1206
