CDM1205-12A-MP-R16-67

12 Pins, Panel Mount, Pc Pins, Rear Fastened M16 x 1.5, A-Coding, Screw Copper Alloy, IP67, M12 Male Circular Connector Jack

Datasheet

Specifications

Type Description
Select
Connector Size M12
Connector Type Jack
Connector Style Male
Mounting Style Panel Mount
Termination Pc Pins
Shielding No
Voltage Rating (Vac) 30
Current Rating (A) 1.5
IP Rating IP67
Number of Positions 12
Pin Size (mm) 0.6
Coding A
Mounting Thread Size M16 x 1.5
Fastening Type Threaded Rear
Color Silver
Contact Finish Gold Plated
Shell Finish Brass with Nickel Plating
Shell Size (mm) 12
Series CDM1205
